Hybrid stepping motor refers to the advantages of hybrid permanent magnet and reactive type. The hybrid stepping motor is still widely used. You can choose according to the actual needs. Below, Kunshan Dongxiong electromechanical Co., Ltd. will quickly understand one of the motor working principles of hybrid stepping motor.

Like reluctance stepping motor, hybrid stepping motor is composed of stator and rotor. The common stator has 8 or 4 poles, and a certain number of small teeth are evenly distributed on the pole surface. The coil on the pole can be electrified in two directions, forming a phase and a phase, B phase and B phase. Its rotor is also composed of two teeth with a certain number of small teeth uniformly distributed on the circumference. The two teeth are staggered by half pitch. An axially magnetized annular magnetic steel is clamped between the two teeth. Obviously, all the teeth on the same segment have the same polarity, while the polarity of two different segments is opposite.

The torque of hybrid motor is larger than that of reluctance motor; In addition, the step angle of hybrid motor is often small, so hybrid stepping motor is often used in the application of limited workspace and requiring small step angle and large torque.
